Description
Security Portable Handheld Metal Detector GC-101H
GC-101H is a light weight portable metal detectors and uses a large-scale CMOS integrated circuit, an electronic buzzer sounds, and has detection functions for ferromagnetic, metal and other objects. Beautiful appearance, small size, convenient use, and strong resistance ability. It is a rare ideal product for checking illegal items.
-
Streamline design, beautiful and generous, and extremely sensitive.
-
Light weight, large detection probe area and fast detection speed.
-
Two alarm modes are available: LED light and sound alarm or vibration alarm.
-
Sturdy and durable, free fall from a height of one meter without damage
-
Voltage indicator light/charging indicator light reminds in time.
-
After installing the rechargeable battery, the product can be fully charged directly.
CG-101H specifications:
Power
9V(6F22)
Operate Frequency
25KHz
Standby Current
< 50mA
Operate Voltage
7V-9V
Indicators
Three indicators:
Red-Alert; Yellow-low voltage(low battery power); Green-power on
Alarm
method
LED
light and sound alarm or vibration alarm
Control
On/Off Switch; Low sensitivity Switch Sensitivity Adjuster
High Sensitivity
10mm at Pin; 40mm at USD 25 Cent
Dimension of Unit
375(L) X 77(W) X 26(H)mm
Weight of Unit
225G
(without battery)
Packing
details
40units/Carton; Carton
box size: 40*34*43cm /12kgs
Color
Silver
gray
Operation
Temperature
-15℃~45℃
Working
environment
Open-air,
scorching sun, indoor ;(Note: cannot work in rain)
Applications:
1. Electronic detection inspection at airports, railway stations and wharfs;
2. Security inspection of customs, public securities, frontier defense and safeguard authorities;
3. Quality inspection of medicine and food commercial systems;
4. Security inspection of important sites and playgrounds;
5. Noble metal detection, such as gold or silver jewelry manufacturing plants.
