Most friendly operation interface Model No.: SA300C
---------------Walk-through Metal Detector
Securina S A300C metal detector gate is one of the industry's most economical and effective walk-through metal detectors. Its microprocessor technology offers greater sensitivity for detecting weapons from the archway to the floor. It is constructed with attractive scratch and mar-resistant laminate with resilient end caps to endure high-volume security checkpoint usage.
Key Features of SA300C Walkthrough Multi-zone Metal Detector:
- Accurate Detection of magnetic, non-magnetic and mixed-alloy metal weapons
- High Discrimination and Throughput
- Exceptional Immunity to environmental interferences
- Unmatched Reliability
- Rapid Installation
- Visualized single zone sensitivity adjustment
- Real multi-zone alarming (Big and small metal can be find at same time)
- 5 security level presets
- 30 locations quick settings
- 100 working frequency bands option
Securina SA300C Walk Through Metal Detector has reliability slashes total cost of ownership. And the overall system is characterized by sturdy, reliable electronic and mechanical construction, and ease of installation.
Securina SA300C Door Frame Metal Detector donnot periodic re-calibration and preventive maintenance required(Accurate Detection). It has built-in self-diagnostic program, power-on self-check, modular structure, multi-language program selection, system automatic wake-up.
Securina SA300C Metal Detector Door adopt DSP highly integrated digital processing technology, more stable performance, more convenient for after-sales service.
Securina SA300C Metal Detector Gate has up to 300 levels of sensitivity calibration, 7inch LCD display, self-diagnosis fault and display.Stable performance, 8/16/24 zones can be switched by software. (33/45 zones accept customization) for SA300C Walkthrough metal detectors.
|Electric current:||80V to 250V|
|Work environment:||-20 degree~+45 degree|
|Outer frame:||2220mm (h) x 820mm (w) X 610mm (d)|
|Inner frame:||2000mm (h) X 700mm (w) X 610mm (d)|
|Detecting zones||8/16/24 zones (33/45zones accept customization)|
|Screen:||7inch LCD screen|
1. Input MBSU battery backup, in time power transfer.
2. Modular structure to easy after service
3. Auto Scan environmental interference at site.
4. Automatically adapt to the working environment.
5. Operation way: Keyboard and remote control (both)
6. LCD friendly operation interface for user
7. Automatically Calibration
8. Two LED light bars on both door panels: Gives alarm corresponding to the height or human body.
9. Detect zone: Free to change as single zone, 8 detect zone, 16 detect zone, 24 zones
10. Advanced broadband detection technology:
Can detect ferrous and non-ferrous articles.
11. Synchronous for different zones
12. Sensitivity adjustable from Level 0 to 300
High: Can detect a small coin
Low: Detect big metal articles such as: Knife, gun, and copper, aluminums, Zinc (more than 150g), ignoring metal in belt button, shoes.
13. Shock proof to avoid false alarm
14. Sound and light alarm
15. Intelligent traffic and alarm counters that calculate traffic flow and resultant alarms.
16. Tamper-Proof: Operate program is protected by password.
17. Available 100 operate frequency, enable max 100pcs WTMD work side by side.
18. Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity
19. Harmless to pregnant woman and heart pacemaker
20. Connect with computer, camera, turnstile, etc (Optional)
21. Self-diagnostic procedures
- Airports, Custom, Stations
- Correctional Facilities
- Law Enforcement, Government Building
- Schools, Shopping Malls, Hotels, Company
- Nuclear Facilities (Security)
- Industries (Security)
- Public Events, Data Processing Centers
